Cayin
HA-6A Tube Headphone Amplifier
$2,499.00 USDEnjoy a live music experience in your own private space with the Cayin HA-6A Tube Headphone Amplifier. Compared to solid state amplifiers, vacuum tube amplifiers are known for their warm, rich, rounded, and full-bodied sound. However, the HA-6A gives the listener options for customizing the sound to suit their tastes and their music.
Carefully Selected Vacuum Tubes
The HA-6A comes with one set of vacuum tubes: Electro-Harmonics EL-34 (warm). A dedicated tube selector switch allows the listener to alternate between the two to suit their preferences. Power rectification comes from a pair of NOS RCA 17AX4GT tubes, while voltage amplification is provided by a pair of Electro-Harmonix 12AU7EH tubes.
Dual Operation Mode
A really nice feature of the HA-6A is dual operation mode, which allows the listener to alter the sound signature with the touch of a button.
Triode Mode
Smooth, lush, rich in harmonics, holographic. The quintessential tube sound. Ideal for vocal and string music.
Ultra-linear Mode
Improved power and extension, clean, energetic, authoritative, transparent. Ideal for music that requires a lot of punch, dynamic, and control.
Impedance Matched Headphone Output
The HA-6A will drive a wide range of headphones. Three gain modes (low, mid, high) make the amplifier compatible with everything from power-hungry planar magnetic headphones to high-sensitivity IEMs.
Practical and Comprehensive
- Three headphone outputs
- Neutrik 6.35 mm single-ended jack
- NIPPON DICS 4.4 mm Pentaconn balanced connection
- Neutrik balanced 4-pin XLR
- Supports two input formats
- XLR balanced
- RCA single-ended
Point-to-point Welding With Premium Wire
The entire circuitry is handwired by skillful craftsman. This yields a circuit design with a high level of transparency and refinement, improving overall efficiency and conductivity.
Astonishing Aesthetics With Handcrafted Details
The HA-6A boasts a modern, industrial design with large VU meters that emit a warm glow and add visual appeal to the handpainted aluminum alloy front panel. Measuring about 14 inches long by 12.7 inches deep and 7.7 inches high, the unit fits nicely in a desktop setup.
The advantage of a transformer coupled tube headphone amplifier is that the matched pair output transformers can deliver genuine balanced driven output for excellent soundstage and separation.
Purist Power Management
Multi-stage independent power supply voltage amplification employs independent regulator design. This minimizes the ripple effect of power interference, ensuring outstanding audio performance that is free from any grain and harshness.
High-Quality Components for Unbeatable Price Performance
Matched-Pair Custom Build EL Output Transformers
- Enable complicated multi-layer winding and multiple impedance output to match with different needs.
- Carefully matched output will sound balanced, natural and realistic across the complete audio spectrum.
Custom Build EL Power Transformers
- Require more space but extremely stable and cost effective.
- Very musical with addictive mid-range performance.
Transformers are the cornerstone of tube amplification. Cayin designs and custom-builds all the transformers of the HA-6A in-house.
High-Precision 24-Step Potentiometer
- Matched-pair resistors
- Low noise
- Durable
- Reliable
Premium Shielded Silver-Plated Cable
Minimizes interference during transmission.
Cayin is a division of Zhuhai Spark Electronic Equipment Co. Ltd. Founded in 1993, the company manufacturers hi-fi products at a variety of price points, including tube amplifiers, CD players, speakers, digital-to-analog converters (DACs), digital audio players (DAPs), and more.
What's in the Box?
- Electro-Harmonix EL34EH Vacuum TUBE (x2)
- JJ 12AU7/ECC82 Vacuum TUBE (x2)
- RCA 17AX4GT Vacuum TUBE (x2)
- User Manual
- AC Power Cord
- Spare Fuses:
- External Main Fuse x2（～220V-240V：T1AL250V；～100V-120V：T2AL250V）
- External Fuse for high voltage x2（T160mAL250V）
Specifications
| Input connector: | XLR, RCA |
|---|---|
| Tube used: | JJ 12AU7/ECC82 ×2, Electro-Harmonix EL34EH x2, RCA 17AX4GT x2 |
| Dimensions: | 360mm x 322mm x 197mm |
| Net weight: | 19.5 kg |
| Fuse: | US Voltage 100V-120V: T2AL25OV |
| Power consumption: | 140W |
| Working condition: | 0℃~40℃; moisture: 20%-80% |
| Storage condition: | -20℃ ~70℃; moisture: 20%-80% |
RATED OUTPUT
KT88
Single Ended
| TR: | 800mW+800mW（L); 1600mW+1600mW (M); 2500mW+2500mW (H) |
|---|---|
| UL: | 1200mW+1200mW（L）; 2200mW+2200mW (M); 3600mW+3600mW (H) |
Balanced
| TR: | 1200mW+1200mW（L); 2000mW+2000mW (M); 3200mW+3200mW (H) |
|---|---|
| UL: | 1900mW+1900mW（L); 3000mW+3000mW (M); 4500mW+4500mW (H) |
EL34
Single Ended
| TR: | 750mW+750mW（L); 1400mW+1400mW（M); 2200mW+2200mW（H） |
|---|---|
| UL: | 1000mW+1000mW（L); 2000mW+2000mW（M); 3300mW+3300mW（H） |
Balanced
| TR: | 1000mW+1000mW（L); 1800mW+1800mW（M); 2900mW+2900mW（H） |
|---|---|
| UL: | 1600mW+1600mW（L); 2800mW+2800mW（M); 4200mW+4200mW（H） |
